ASTM A182 F11 Cl2 Weld Neck Flange Essential Component for Safe and Operation in Power Generation

Detail produk:

Tempat asal:	CINA
Nama merek:	YUHONG
Sertifikasi:	API , ABS, DNV, GL , LR, NK.
Nomor model:	ASTM A182 F11 CL2

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Case ply-wooden / besi / bundel dengan tutup plastik
Waktu pengiriman:	20-80
Syarat-syarat pembayaran:	L/c, t/t

Kontak

Semua produk

Pipa Seamless Stainless Steel (290)

Tabung Mulus Stainless Steel (277)

Pipa Stainless Steel Dupleks (127)

Tabung Baja Tahan Karat Dupleks (29)

Tabung jarum (107)

Tabung Sirip (631)

Penukar panas (17)

Tabung Penukar Panas (424)

Paket tabung penukar panas (37)

Lembar Tabung Penukar Panas (116)

penyekat penukar panas (36)

Pendingin udara (8)

Kapal Tekanan (4)

Pipa Las Stainless Steel (57)

Tabung Las Stainless Steel (114)

Nikel paduan pipa (261)

Tabung Paduan Nikel (79)

Tabung paduan tembaga (227)

Tabung Baja Paduan (184)

tabung titanium (10)

Bright Annealed Tube (153)

Tabung Boiler (145)

pemasangan baja (804)

Flensa Baja (590)

Yang lain (391)

Bagian Pelapis (7)

Detil Deskripsi produk

Bahan:	F11 CL2	Nama Produk:	Flensa panas stainless steel
Tekanan:	150lb,300lb,600lb,900lb,1500lb	Standar:	ANSI B16.5 ASME B16.47 SERI A(MSS SP44)
Jenis:	Flensa Berulir, Flensa Selip Pada, Flensa Soket Las, Flensa Leher las, Flensa Sambungan LAP	Proses:	Ditempa, Pengeboran / Bending / Stamping, Pengecoran, pengecoran pasir & mesin CNC, Penempaan + mesi
Perawatan permukaan:	Perlakuan Panas, Galvanis, Oksidasi Hitam, Kustomisasi, Pengawetan	Inspeksi:	Inspeksi Properti Mekanis, Pabrik Atau Pihak Ketiga Ditugaskan, Inspeksi 100%.
Menyoroti:	ASTM A182 F11 weld neck flange , steel flange for power generation , Cl2 weld neck flange with warranty

ASTM A182 F11 Cl2 Weld Neck Flange Essential Component for Safe and Operation in Power Generation

The ASTM A182 F11 Cl.2 welding neck flange is a forged pipe connection designed for demanding high-temperature, high-pressure conditions.

It is manufactured from chromium-molybdenum alloy steel (Grade F11) and subjected to a normalizing and tempering (Class 2) heat treatment, resulting in excellent high-temperature strength, creep resistance, and corrosion resistance.

Its signature long tapered neck design ensures seamless butt welding with the pipe, significantly reducing stress concentration.

As a result, it is widely used in core piping systems in thermal power generation, petrochemicals, and refining, serving as a critical component for safe and reliable operation.

Composition Chart of A182 F11 Cl2 Weld Neck Flanges

Grade	C	Mn	Si	S	P	Cr	Mo
ASTM A182 F11	0.05 - 0.15	0.3 - 0.6	0.5 - 1	0.03	0.03	1 - 1.5	0.044 - 0.65

ASME SA182 F11 Class 2 Flange Mechanical Properties Chart

Grade	Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation %
ASTM A182 F11 Flange	205	415	20

ASTM A182 F11 Cl2 Flange Application

Power Generation: In fossil fuel and thermal power plants, it is crucial for connecting steam lines, boiler feedwater systems, and high-energy fluid circuits, withstanding high temperatures and pressures.

Petroleum Refining: Used in refining processes such as crude oil distillation, catalytic cracking, and hydrotreating, it resists corrosion from hydrocarbons and hydrogen.

Petrochemical Plants: Facilities used to produce ethylene, ammonia, and methanol handle corrosive chemicals and high temperatures.

ASTM A182 F11 Cl2 Weld Neck Flange Essential Component for Safe and Operation in Power Generation 0
