ASTM A335 / ASME SA335 UNS K90901 P91 Boiler Tube EN 1.4903 Alloy Steel Seamless Pipe

Detail produk:

Tempat asal:	Cina
Nama merek:	YUHONG
Sertifikasi:	ISO9001-2008, API 5L, API 5CT, PED, AD-2000, EN10204-3.1B
Nomor model:	ASTM A335 P91 Pipa tanpa jahitan baja paduan

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	Air Dingin Bawaan
Kemasan rincian:	Kotak kayu lapis / Kotak Besi / Bundel dengan tutup plastik
Waktu pengiriman:	7 hari
Syarat-syarat pembayaran:	L/C, T/T

Kontak

Semua produk

Pipa Seamless Stainless Steel (342)

Tabung Mulus Stainless Steel (335)

Pipa Stainless Steel Dupleks (134)

Tabung Baja Tahan Karat Dupleks (39)

Tabung jarum (170)

Tabung Sirip (733)

Penukar panas (35)

Tabung Penukar Panas (472)

Paket tabung penukar panas (52)

Lembar Tabung Penukar Panas (128)

penyekat penukar panas (39)

Pendingin udara (14)

Kapal Tekanan (4)

Pipa Las Stainless Steel (61)

Tabung Las Stainless Steel (134)

Nikel paduan pipa (276)

Tabung Paduan Nikel (104)

Tabung paduan tembaga (257)

Tabung Baja Paduan (217)

tabung titanium (21)

Bright Annealed Tube (174)

Tabung Boiler (155)

pemasangan baja (874)

Flensa Baja (671)

Yang lain (409)

Bagian Pelapis (9)

Detil Deskripsi produk

Nama Produk:	Pipa Seamless Baja Paduan	Standar:	ASTM A335 / ASME SA335
Bahan:	P91, UNS K90901, EN 1.4903	Od:	1/2 "hingga 24" atau besar
WT:	SCH 10s Ke SCH XXS	Panjang:	Acak Tunggal, Acak Ganda & Panjang Potong
Akhir:	Ujung Biasa, Ujung Miring	Jenis:	Mulus
Aplikasi:	Pembangkit Listrik, Petrokimia, Tabung Boiler, Industri Minyak & Gas
Menyorot:	Pipa Mulus Baja Paduan ASTM A335 P91, Tabung Boiler Baja Mulus UNS K90901

ASTM A335 / ASME SA335 P91 Alloy Steel Seamless Pipe for High-Temperature Service

ASTM A335 P91 (UNS K90901 / EN 1.4903) is a high-alloy martensitic steel with ~9% Chromium, Molybdenum, Vanadium, Niobium, and Nitrogen. Designed for boiler tubes and main steam piping, it offers exceptional creep strength up to 620°C and superior oxidation resistance—allowing thinner, lighter walls than traditional low-alloy grades. It is mandatory to use this material in the normalized + tempered condition. Critical warning: It is air-hardening; therefore, all welded joints require strict preheating (200–250°C) and mandatory Post-Weld Heat Treatment (730–760°C) to prevent cracking.

Key Features & Advantages (Why High-Alloyed Grade P91?)

Superior Oxidation Resistance: The ~9% Chromium content provides significantly better resistance to steam-side oxidation and high-temperature flue gas corrosion compared to low-alloy grades (e.g., T22/P22).
High Thermal Stability: Retains strength and structure integrity at extreme temperatures.
Low Thermal Expansion: Lower than austenitic stainless steels (e.g., 304/316), allowing for thinner wall thicknesses and better fatigue resistance under thermal cycling.
Reduced Wall Thickness: Excellent creep strength allows designers to use thinner pipe walls than P22/T22, reducing weight and thermal inertia.

Equivalent Material of ASTM A335 / ASME SA335 UNS K90901 P91 Boiler Tube EN 1.4903 Alloy Steel Seamless Pipe

ASTM	ASME	Equivalent material
A335 P 91	ASME SA 335 P91	1.4903, K90901, X10CrMoVNb9-1

Chemical Composition of ASME SA335 UNS K90901 P91 Boiler Tube EN 1.4903 Alloy Steel Seamless Pipe

Element	Grade	P5	P9	P11	P22	P91	P91 shall also include the following:
Element	UNS	K41545	S50400	K11597	K21590	K91560	P91 shall also include the following:
Carbon		0.15 max	0.15 max	0.05 – 0.15	0.05 – 0.15	0.08 – 0.12	V at 0.18 – 0.25
Manganese		0.30 – 0.60	0.30 – 0.60	0.30 – 0.60	0.30 – 0.60	0.30 – 0.60	N at 0.030 – 0.070
Phosphorous, max		0.025	0.025	0.025	0.025	0.020	Ni at 0.40 max
Sulfur, max		0.025	0.025	0.025	0.025	0.010	Al at 0.02 max
Silicon		0.50 max	0.25 – 1.00	0.50 – 1.00	0.50 max	0.20 -0.50	Cb at 0.06 – 0.10
Chromium		4.00 – 6.00	8.0 – 10.0	1.00 – 1.50	1.90 – 2.60	8.00 – 9.50	Ti at 0.01 max
Molybdenum		0.45 -0.65	0.90 – 1.10	0.44 – 0.65	0.87 – 1.13	0.85 – 1.05	Zr at 0.01 max

Mechanical Properties of ASME SA335 UNS K90901 P91 Boiler Tube EN 1.4903 Alloy Steel Seamless Pipe

Grade	Tensile strength(MPa)	Yield strength(MPa)	Elongation(%)	Impact energy(J)	Hardness
P11	≥ 415	≥ 205	≥ 22	≥ 35	≤ 163HB
P12	≥ 415	≥ 220	≥ 22	≥ 35	≤ 163HB
P22	≥ 415	≥ 205	≥ 22	≥ 35	≤ 163HB
P5	≥ 415	≥ 205	≥ 22	≥ 35	≤ 187HB
P91	585~760	≥ 415	≥ 20	≥ 35	≤ 250HB
P92	≥ 620	≥ 440	≥ 20	≥ 35	250HB

Application

A335/SA335 P91 is suitable for bending, flanging (vanstoning), and similar forming operations and for fusion welding. Its commonly used in below usages.

Superheaters & Reheaters (Boiler tubes).
Main Steam Piping and hot reheat piping.
Headers and manifolds in supercritical and ultra-supercritical coal-fired power plants.
Nuclear power heat exchangers.
Petrochemical high-temperature furnace tubes.
