ASTM B366 N08810 N08820 Equal Tee Incoloy 800H/800HT Tee, High Temp Corrosion Resistant For Piping System

Detail produk:

Tempat asal:	Cina
Nama merek:	YUHONG
Sertifikasi:	API, PED , ABS, DNV, BV, LR
Nomor model:	ASTM B366 NO8810&N08820

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 buah
Harga:	Dapat dinegosiasikan
Kemasan rincian:	KASUS KAYU LAPIS ATAU PALLET
Waktu pengiriman:	Tergantung pada kuantitas
Syarat-syarat pembayaran:	T/T, L/C pada pandangan
Menyediakan kemampuan:	10000 BUAH per bulan

Kontak

Semua produk

Pipa Seamless Stainless Steel (332)

Tabung Mulus Stainless Steel (324)

Pipa Stainless Steel Dupleks (134)

Tabung Baja Tahan Karat Dupleks (37)

Tabung jarum (158)

Tabung Sirip (705)

Penukar panas (31)

Tabung Penukar Panas (459)

Paket tabung penukar panas (49)

Lembar Tabung Penukar Panas (125)

penyekat penukar panas (39)

Pendingin udara (11)

Kapal Tekanan (4)

Pipa Las Stainless Steel (61)

Tabung Las Stainless Steel (132)

Nikel paduan pipa (273)

Tabung Paduan Nikel (103)

Tabung paduan tembaga (250)

Tabung Baja Paduan (210)

tabung titanium (20)

Bright Annealed Tube (172)

Tabung Boiler (152)

pemasangan baja (862)

Flensa Baja (660)

Yang lain (406)

Bagian Pelapis (8)

Detil Deskripsi produk

Standar:	ASTM B366 / ASME SB366	Nama Produk:	Setara Tee
Od:	Sesuai permintaan klien	Wt:	Jadwalkan 10 detik hingga Jadwal XXS
jenis:	Mulus	Sertifikat:	ISO TUV BV SGS, dll.
Standar Dimensi:	ASME/ ANSI B16.9	Aplikasi:	kimia gas minyak, lingkungan laut, dll.
Menyoroti:	ASTM B366 Incoloy 800H equal tee , high temperature corrosion resistant tee , N08810 N08820 piping system tee

ASTM B366 N08810 N08820 Equal Tee Incoloy 800H/800HT Tee, High Temp Corrosion Resistant For Piping System

ASTM B366 N08810 & N08820 equal diameter tees are special alloy pipe fittings designed to withstand extremely harsh high-temperature, high-pressure, and corrosive conditions, fundamentally solving the connection problems of core piping systems in the petrochemical, energy, and high-end manufacturing industries.

800H (N08810) - High-Temperature Reinforced Version: By specially increasing the carbon content (0.05%-0.10%) and combining it with high-temperature solution treatment, coarse austenitic grains are obtained, resulting in excellent creep resistance and end-of-life fracture strength at high temperatures. Due to its high chromium and high nickel content, it exhibits excellent resistance to stress corrosion cracking in corrosive media such as chlorides and high-temperature, high-pressure water.

800HT (N08820) - Enhanced High-Temperature Performance: Based on 800H, by more strictly controlling the content of carbon, aluminum, and titanium, its creep rupture strength at high temperatures is higher than that of 800H, while maintaining good strength and excellent resistance to oxidation and carburization.

Chemical Composition
Element	N08810 (Incoloy 800H)	N08820 (Incoloy 800HT)
Nickel (Ni)	30.0 – 35.0	30.0 – 35.0
Chromium (Cr)	19.0 – 23.0	19.0 – 23.0
Iron (Fe)	≥ 39.5 (Balance)	≥ 39.5 (Balance)
Carbon (C)	0.05 – 0.10	0.06 – 0.10
Manganese (Mn)	≤ 1.50	≤ 1.50
Silicon (Si)	≤ 1.00	≤ 1.00
Sulfur (S)	≤ 0.015	≤ 0.015
Copper (Cu)	≤ 0.75	≤ 0.75
Aluminum (Al)	0.15 – 0.60	0.25 – 0.60
Titanium (Ti)	0.15 – 0.60	0.25 – 0.60
Cobalt (Co)	—	≤ 2.00

Mechanical Properties
Property	N08810 (Incoloy 800H)	N08820 (Incoloy 800HT)
Tensile Strength (min.)	≥ 520 MPa (75 ksi)	≥ 520 – 870 MPa
Yield Strength – 0.2% offset (min.)	≥ 205 MPa (30 ksi)	≥ 205 – 345 MPa
Elongation (min.)	≥ 30%	≥ 30%
Hardness	≤ 200 HB (typical)	≤ 200 HB (typical)

Applications

Ethylene cracking furnace tubes;
Bellows and flare heads in oil refineries;
Intermediate heat exchangers in fourth-generation reactors;
Heat transfer tubes in high-temperature gas-cooled reactor steam generators;
Superheaters and reheaters in ultra-/ultra-supercritical boilers for thermal and solar thermal power generation.
