ASTM A213 T5 Alloy Steel Seamless Tube Chromium Molybdenum Steel for High Temperature Service

Detail produk:

Tempat asal:	Tiongkok
Nama merek:	YUHONG
Sertifikasi:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Nomor model:	ASTM A213 T5

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	500kgs
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Case ply-wooden / besi / bundel dengan tutup plastik
Waktu pengiriman:	15-20 hari
Syarat-syarat pembayaran:	L/C, T/T
Menyediakan kemampuan:	800 Ton/bulan

Kontak

Semua produk

Pipa Seamless Stainless Steel (290)

Tabung Mulus Stainless Steel (277)

Pipa Stainless Steel Dupleks (127)

Tabung Baja Tahan Karat Dupleks (29)

Tabung jarum (107)

Tabung Sirip (631)

Penukar panas (17)

Tabung Penukar Panas (424)

Paket tabung penukar panas (37)

Lembar Tabung Penukar Panas (116)

penyekat penukar panas (36)

Pendingin udara (8)

Kapal Tekanan (4)

Pipa Las Stainless Steel (57)

Tabung Las Stainless Steel (114)

Nikel paduan pipa (261)

Tabung Paduan Nikel (79)

Tabung paduan tembaga (227)

Tabung Baja Paduan (184)

tabung titanium (10)

Bright Annealed Tube (153)

Tabung Boiler (145)

pemasangan baja (804)

Flensa Baja (590)

Yang lain (391)

Bagian Pelapis (7)

Detil Deskripsi produk

Standar:	ASTM A213/ASME SA213	Tingkat material:	T5 (UNS S50100)
Jenis Produk:	Tabung tanpa jahitan	Bahan:	Baja Paduan Kromium-Molibdenum
Aplikasi:	Tabung Boiler Suhu Tinggi	Kisaran ukuran:	OD 1/4" hingga 4"
Menyoroti:	ASTM A213 T5 alloy steel tube , chromium molybdenum steel tube , high temperature seamless steel tube

ASTM A213 T5 Alloy Steel Seamless Tube Chromium Molybdenum Steel for High Temperature Service

YUHONG GROUP leverages 35 years of industrial expertise and a global presence spanning 85 countries to deliver high-performance alloy steel tubing for critical high-temperature applications. Our ASTM A213 T5 chromium-molybdenum alloy seamless tubes are engineered for the power generation and petrochemical industries, where elevated-temperature resistance and durability are paramount.

With decades of experience in metallurgy and precision manufacturing, we provide ASTM-compliant tubing solutions that ensure reliability in boiler systems, heat exchangers, and high-pressure piping applications worldwide. Our commitment to quality and technical excellence makes us a trusted partner for energy and process industry clients worldwide.

Chemical Composition of Grade T5 (UNS K41545)

Element	Requirement (%)
Carbon (C)	0.15 max
Manganese (Mn)	0.30 - 0.60
Phosphorus (P)	0.025 max
Sulfur (S)	0.025 max
Silicon (Si)	0.50 max
Nickel (Ni)	...
Chromium (Cr)	4.00 - 6.00
Molybdenum (Mo)	0.45 - 0.65
Vanadium (V)	...
Boron (B)	...

Heat Treatment Requirements for Grade T5 (UNS K41545)

Parameter	Specification	Notes
Grade	T5	Chromium-Molybdenum Alloy Steel
UNS Number	K41545
Heat Treat Type	Full or Isothermal Anneal, or Normalize and Temper	Multiple approved heat treatment processes are available.
Subcritical Annealing or Tempering Temperature	1200 to 1350 °F [650 to 730 °C]	This is a critical step following normalization (if performed).
Subcritical Annealing or Tempering Temperature (Alternative)	1250 °F [675 °C]	A specific temperature within the range is called out.
ASTM Grain Size No.	Not Specified	-

Mechanical Properties of Grade T5 (UNS K41545)

Property	Requirement	Notes
Grade	T5	Low Alloy Steel (Chromium-Molybdenum)
UNS Designation	K41545
Tensile Strength, min	60 ksi [415 MPa]
Yield Strength (0.2% Offset), min	30 ksi [205 MPa]
Elongation in 2 in. or 50 mm, min	30%	See footnotes a, b, c for test exceptions
Hardness, max	163 HBW / 170 HV / 85 HRB	Brinell, Vickers, or Rockwell B Scale

Key Application Advantages of ASTM A213 T5 Alloy Steel Seamless Tube

1. Excellent High-Temperature Performance
The chromium-molybdenum alloy composition (T5 grade) provides outstanding oxidation resistance and sustained strength at temperatures up to 538°C (1000°F), making it ideal for high-temperature service in boilers and heat exchangers.
2. Superior Corrosion & Oxidation Resistance
Offers enhanced resistance to oxidation, sulfidation, and creep under elevated temperatures, significantly extending service life in thermal power plants and refinery applications.
3 . Optimized Thermal Efficiency
The seamless tube structure ensures uniform wall thickness and smooth internal surface, promoting efficient heat transfer and reducing energy consumption in power generation systems.
4 . Proven Reliability in Critical Applications
Widely used in superheaters, reheaters, and heat exchanger components, demonstrating reliable performance under cyclic thermal conditions and high-pressure environments.
5 . Global Standard Compliance
Manufactured in full compliance with ASTM A213/ASME SA213 standards, ensuring material quality and safety for international power and process industry projects.

ASTM A213 T5 Alloy Steel Seamless Tube Chromium Molybdenum Steel for High Temperature Service 0
