ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified

ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified

  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
  • ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
ASTM SB163 N04400 Seamless Pipe Monel 400 EN10204 3.1 Certified
Detail produk:
Tempat asal: CINA
Nama merek: YUHONG
Sertifikasi: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Nomor model: ASTM SB163 N04400
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 100kgs
Harga: Dapat dinegosiasikan
Kemasan rincian: Ply-wooden Case / Iron Case / Bundel dengan Tutup plastik / Woven Case
Waktu pengiriman: Tergantung pada kuantitas
Syarat-syarat pembayaran: L/c, t/t
Menyediakan kemampuan: 1000 ton per bulan
Kontak
Semua produk
Pipa Seamless Stainless Steel (290)
Tabung Mulus Stainless Steel (277)
Pipa Stainless Steel Dupleks (127)
Tabung Baja Tahan Karat Dupleks (29)
Tabung jarum (107)
Tabung Sirip (631)
Penukar panas (17)
Tabung Penukar Panas (424)
Paket tabung penukar panas (37)
Lembar Tabung Penukar Panas (116)
penyekat penukar panas (36)
Pendingin udara (8)
Kapal Tekanan (4)
Pipa Las Stainless Steel (57)
Tabung Las Stainless Steel (114)
Nikel paduan pipa (261)
Tabung Paduan Nikel (79)
Tabung paduan tembaga (227)
Tabung Baja Paduan (184)
tabung titanium (10)
Bright Annealed Tube (153)
Tabung Boiler (145)
pemasangan baja (804)
Flensa Baja (590)
Yang lain (391)
Bagian Pelapis (7)
Detil Deskripsi produk
Tingkat material: UNS N04400 / Monel 400 Jenis produk: Pipa paduan nikel-tembaga yang mulus
Kepatuhan sertifikasi: ASTM SB163, ASME SB163, EN 10204 3.1 Akhiri Jenis Koneksi: Ujung Polos, Ujung Miring, Berulir
Permukaan akhir: Annealed & acar, dipoles Resistensi korosi: Air laut, asam, lingkungan alkali
Menyoroti:

ASTM SB163 Monel 400 seamless pipe

,

N04400 nickel alloy pipe EN10204 certified

,

Monel 400 pipe with 3.1 certification


ASTM SB163 UNS N04400 Nickel-Copper Alloy Seamless Pipe



N04400 Alloy Pipe Overview


ASTM SB163 UNS N04400 is a nickel-copper alloy seamless pipe renowned for exceptional corrosion resistance in acidic, alkaline, and marine environments. With high strength, thermal stability (up to 538°C), and superior fabricability, it’s ideal for critical applications in chemical processing, oil & gas, and marine engineering. Manufactured to ASTM SB163 standards, these pipes ensure reliability in extreme conditions.



N04400 Chemical Composition


The corrosion resistance of N04400 stems from its precise nickel-copper balance. Key elements include:


Element Content (%) Element Content (%)
Nickel (Ni) 63.0 min Copper (Cu) 28.0–34.0
Iron (Fe) 2.0 max Manganese (Mn) 2.0 max
Carbon (C) 0.3 max Sulfur (S) 0.024 max
Silicon (Si) 0.5 max



N04400 Equivalent Grades


N04400 alloy is globally recognized under these designations:


Standard Equivalent Grade Standard Equivalent Grade
UNS N04400 EN NiCu30Fe
DIN 2.4360 JIS NW4400
BS NA 13 ASME SB163



N04400 Mechanical Properties


Meets ASTM SB163 requirements for high strength and ductility:


Property Value
Tensile Strength 550 MPa (min)
Yield Strength (0.2%) 240 MPa (min)
Elongation (%) 35% (min)
Hardness (Rockwell B) 90 HRB (max)



N04400 Dimensional Tolerances


Precision-engineered to ASTM SB163 specifications:


Parameter Tolerance
Outer Diameter ±0.8% (OD ≤ 50mm)
±0.5% (OD > 50mm)
Wall Thickness +20% / -0% (Schedules 5S-XXS)
Length +3 mm / -0 mm (Cut Length)



N04400 Alloy Application Domains


N04400 pipes excel in corrosive and high-stress environments:


  • Marine Engineering: Seawater piping, pump shafts.


  • Chemical Processing: HCl/HF acid handling, heat exchangers.


  • Oil & Gas: Offshore platforms, valves, and fittings.


  • Power Generation: Feedwater heaters, condenser tubes.


  • Desalination Plants: Brine heaters, evaporator tubes.
